Item

1000W

blade diameter

2m

material of the blades

Fiberglass-Reinforced Plastic

rated rotor speed

150r/min

rated speed

12m/s

rated Power

1000W

max Power

1200w

Max start torque (n/m)

＜0.4

output voltage

48V/24v

start up wind speed

2.5(m/s)

work speed

3-25(m/s)

security wind speed

 50(m/s)

eight of guy cable tower

6(m)

generator type

3-phase AC PM

top quality (generator +blades)

60kg

Suggest batteries

  4pcs 12v150ah

Service life

  >15 years

output controller system

Wind solar hybrid controller，Off--grid inverter

Mated solar panel

48v200w--400w

Class of insulation

B

Material of enclosure

20# seamless tube

Material of magnet steel

neodymium-iron-boron 38sh

Material of stator

QZY-2/180/470

Corrosion prevention

Zinc coated、painting

Blades shape

3 FRP blades

Over speed protection

Yaw automatically, electromagnetism protection

Support loads

Small refrigerator, washing machine、water pump(550)、electric cooker、color TV、lighting、electric fan、charging、warming, computor, electric tools below 600w
