XH-3KW

XH-5KW

XH-10KW

rated power W

3000

5000

10000

maximum power W

4500

7200

12000

Rotor diameter m

3.0

3.6

4.4

Number of blades (blade

rotation assembly)

3 cover

3 cover

3 cover

Blade length m (blade rotation assembly)

1.8 meters, with 2 blades and a total height of 4.2 meters for the self transmission assembly

2.4 meters, with 2 blades and an automatic transmission assembly, with a total height of 5.4 meters

3 meters, with 2 blades and a total height of 6.8 meters for the self transmission

assembly

Blade width m

800mm

800mm

1200mm

Blade form

Resistance type

Resistance type

Resistance type

Wind turbine operation

mode

Revolution mode

Revolution mode

Revolution mode

SPEED (r/min)

48

40

30

Rated wind speed m/s

12

12

13

Start wind speed m/s

3

3

3

work wind speed m/s

3-25

3-25

3-25

Security wind speed m/s

40

40

40
